CDM-600L Satellite Modem
Preface
Environmental
The CDM-600L must not be operated in an environment where the unit is exposed to
extremes of temperature outside the ambient range 0 to 50°C (32° to 122°F),
precipitation, condensation, or humid atmospheres above 95% RH, altitudes (un-
pressurised) greater than 2000 metres, excessive dust or vibration, flammable gases,
corrosive or explosive atmospheres.
Operation in vehicles or other transportable installations that are equipped to provide a
stable environment is permitted. If such vehicles do not provide a stable environment,
safety of the equipment to EN60950 may not be guaranteed.
Installation
AC Modem Installation:
The installation and connection to the line supply must be made in compliance to local or
national wiring codes and regulations.
The CDM-600L is designed for connection to a power system that has separate ground,
line and neutral conductors. The equipment is not designed for connection to power
system that has no direct connection to ground.
The CDM-600L is shipped with a line inlet cable suitable for use in the country of
operation. If it is necessary to replace this cable, ensure the replacement has an equivalent
specification. Examples of acceptable ratings for the cable include HAR, BASEC and
HOXXX-X. Examples of acceptable connector ratings include VDE, NF-USE, UL, CSA,
OVE, CEBEC, NEMKO, DEMKO, BS1636A, BSI, SETI, IMQ, KEMA-KEUR and
SEV.
International Symbols:
Symbol
~
DC Modem Installation:
The DC input CDM-600L is connected to a nominal 48 VDC prime power source. The
DC input is isolated from the chassis and from the DC output to the BUC if equipped
with internal BUC power supply. The chassis may be connected to a local system ground
Definition
Alternating Current
Fuse
xi
Symbol
Definition
Protective Earth
Chassis Ground
Revision 2
MN/CDM600.IOM
