CDM-600L Satellite Modem
Front Panel Operation
6.3.3.10
INFO: REMOTE
REMOTE-CONTROL= LOCAL
INTERFACE = RS-232
This screen shows if the unit is in Local or Remote mode, provides the details of the
electrical interface type selected, the unit's address and the baud rate selected. Pressing
ENTER takes the user back to the previous menu.
6.3.3.11
INFO: ALARMS MASK
ALARMS MASKED: TX-AIS
This screen shows only the alarm(s) which are currently masked:
•
•
•
•
•
•
•
If an alarm is not masked, a blank is displayed in the relevant screen position.
6.3.3.12
INFO: MISC
MISCELLANEOUS:
1:1 SWITCH = NOT CONNECTED
This screen shows the following:
•
•
•
AGC
TX-AIS
RX-AIS
BUF-SLIP
AGC
EBNO
SAT
TERR
NORMAL
Test Mode
1:1 Link Status
Redundancy Status
ADDRESS= 0000
9600 BAUD N81
RX-AIS
BUF-SLIP
EBNO
SAT
ONLINE
6–33
Revision 2
MN/CDM600L.IOM
