Figure 10-5. Single-Source Multiple Modems (Looming) - Comtech EF Data CDM-600L Installation And Operation Manual

CDM-600L Satellite Modem
Clock Modes and Drop and Insert (D&I)
MODEM
DDI
DDO
Terrestrial Trunk
Figure 10-6. Single-Source Multiple Modems (Daisy Chain)

Figure 10-5. Single-Source Multiple Modems (Looming)

IDI
IDI
IDO
Multiple Modem Drop & Insert Application: This application shows how the loop is extended
to one or more additional modems.
DDO- IDI connection may be made internally using Loop = Y under D&I menu.
BIT ERROR TEST
MODEM
10–10
Revision 2
MN/CDM600L.IOM
- - - - - - - - - - Receive
___________ Transmit
MODEM
