SpectraLink Corporation
Message
Description
System Busy
y...y = SVP Server IP Address.
yyy.yyy.yyy.yyy
SVP Server has reached call capacity.
System Locked
NetLink SVP Server is locked.
(with Busy Tone)
TFTP ERROR(x):yy
A failure has occurred during a TFTP software
download. (x) = The file number which was
being downloaded; yy is an error code
describing the particular failure. Possible
error codes are:
01 = TFTP server did not find the requested
file.
02 = Access violation (reported from TFTP
server).
07 = TFTP server reported "No such user"
error.
16 = No TFTP server address.
81 = File put into memory did not CRC.
FF = Timeout error. TFTP server did not
respond within a specified period of time.
Too Many Errors
The handset continues to reset and cannot
be recovered.
Unknown
A phrase is missing from the phintl file.
xx:yy:zz
Unsupported Codec
The proxy server has requested using a codec
not supported by the handset.
Updating ...
The handset is internally updating its
software images.
Updating Code...
Handset is downloading new software into
memory. The number icons at the bottom of
the display indicate which file number is
currently being downloaded. This message
also displays a progress bar. When the
progress bar fills the display line the update
operation is complete on that file.
Waiting...
Handset has attempted some operation
several times and failed.
Wrong Code Type
The software loaded into the handset is
incorrect for this model phone.
PN: 72-1089-02-E.doc
Configuration and Administration—NetLink e340/h340/i640 Wireless Telephone
Action
All call paths are in use, try the call again
in a few minutes.
Try call again later, system has been
locked for maintenance.
Error code 01, 02, 07, or 16 - check the
TFTP server configuration.
Error code 81, the handset will attempt to
download the file again.
For other messages, power off the handset,
then turn it on again to retry the download.
If the error repeats, note it and contact
SpectraLink Customer Support.
Fatal error. Return handset to SpectraLink.
Download new software from the
Software
SpectraLink website per
Maintenance
.
Check proxy server configuration for
supported codecs and reconfigure if
necessary.
None. The handset may do this briefly after
a download. This is informational only.
None. When the progress bar fills the
display line the update operation is
complete on that file.
Do not turn the handset off during this
operation.
None. The handset is waiting for a
specified period of time before attempting
that operation again.
Replace the software image on the TFTP
server with software that is correct for the
handset model.
with SIP
Page 62
