User-Defined Preferences - SpectraLink NetLink e340 Configuration And Administration Manual

SpectraLink Corporation
then enter the digits that represent the site's domain. Note that both digits must be
entered.
01 North America
Europe (except Spain and France); Japan (channels 1-13)
02
04 Spain
05 France
As of this writing, Spain and France are adopting the general European
regulatory rules. Check with your wireless LAN administrator or supplier
regarding which domain to enter in these countries.
Transmit Power
Available Transmit Power is regulated by domain. The Regulatory Domain setting
above affects the options available for this setting. The default setting is
which in North America is 100 mW. The Maximum in other domains is 30 mW.
Transmit Power may be set to a lower number if necessary by selecting one of the
other levels. If changed from the default, ensure the Transmit Power setting is the
same on all handsets and all APs.
Power is limited to 30mW in regulatory domains other than North America.
See Appendix A for the full list of certified countries and the corresponding
domain for each.
Diagnostics
Run Site Survey
The Site Survey
running immediately upon selecting this option. See the Diagnostic Tools section for
more information about site survey.
Diagnostics Mode
See the Diagnostic Tools section for a detailed explanation of the
options.
Syslog Mode
See the Diagnostic Tools section for a detailed explanation of the
options.
Restore Defaults
The
Restore Defaults
License Option to their factory defaults.
3.2

User-defined Preferences

The following user-defined preferences are also covered in the NetLink
e340/h340/i640 Wireless Telephone User Guide. The system administrator can refer
to this list for more information about customizing handset settings.
To configure the following options, the handset must acquire the system (no error
message may display) and be at the extension display. This is the standby mode.
PN: 72-1089-02-E.doc
Configuration and Administration—NetLink e340/h340/i640 Wireless Telephone
mode is activated by selecting this option. The site survey starts
option will set all user and administrative parameters except
with SIP
Maximum
Diagnostics Mode
Syslog Mode
Page 24
