Screen 2
• Jitter is the average error or "wobble" in received packet timing, in microseconds
• Last successful transmit data rate (LastRate)
• Gateway type (GatewyType)
Where:
mnemo: a mnemonic that indicates what type of gateway is being used
• 11Mb – This system can run at 11 Mb/s.
Screen 3
Screen 3 contains a list of the APs that are heard and the following parameters from
each AP:
• Indicator as to whether this is the current AP, or an index into the list of other
APs heard (C indicates current).
• Last 2 octets of the MAC address of the AP
• Channel number
• Signal strength
• Either the 802.11 Association ID from the current AP or a mnemonic for the
reason code indicating why the handset did not hand off to this other AP.
Where:
AP mnem: a mnemonic indicating the reason code:
• Unkn: reason unknown
• Weak: signal strength too weak
• Rate: one or more basic rates not supported
• Full: AP can not handle bandwidth requirements
• AthT: authentication timeout
• AscT: association timeout
• AthF: authentication failure
• AscF: association failure
• SecT: security handshake timeout
• SecF: security handshake failure
• Cnfg: AP not configured correctly for security, QoS mode or infrastructure
network
PN: 72-1089-02-E.doc
Configuration and Administration—NetLink e340/h340/i640 Wireless Telephone
J i t t e r
L a s t R a t e
G a t e w y T y p e
C : m m m m c h
1 : m m m m c h
2 : m m m m c h
3 : m m m m c h
n n n n n
n n n n n
m n e m o
- s s a i d
- s s m n e m
- s s m n e m
- s s m n e m
with SIP
