SpectraLink NetLink i640 Technical Bulletin

SpectraLink Drop Test Description
Date:
Software Version:
Hardware Version:
Product Type:
Access Level:

Description

This document briefly describes SpectraLink's standardized drop test method and pass-fail criteria.
SpectraLink's drop test is derived from the free fall testing procedure defined in IEC/ANSI 60068-2-32 and
enables reproducible assessments of the drop test performance and durability of SpectraLink Link WTS and
NetLink Wireless Telephones.

Drop Test Methodology

The test is designed to simulate falls which a given handset model might undergo during normal operation,
and to verify that it meets or exceeds the handset's durability specification. It is based on falls in random
orientation onto a hard unpadded (ceramic) floor surface from a specified drop height (listed in the table
below). After each fall, the victim device is visually examined and electrically and mechanically verified, as
outlined below.

Drop Test Sampling

In an effort to ensure consistent maximum quality of newly manufactured products, SpectraLink performs
these tests with a statistically significant sample and on a quarterly basis.

Drop Test Pass Criteria

After each drop:
•The handset must be capable of being registered to a system
•The handset must be capable of placing and receiving calls with voice quality indistinguishable from newly
manufactured devices
•No mechanical PC board damage or sign of loose components are evident
•Cosmetic scratching or scarring to the plastic enclosure are acceptable; however, broken or cracked
enclosures are not acceptable
•Separation and/or damage to the Battery Pack, including battery failures, are acceptable

Handset Specifications

Each SpectraLink Wireless Telephone has a durability specification that includes drop test survivability, as
listed in the following table:
Model
NetLink e340 Wireless Telephone
NetLink h340 Wireless Telephone
NetLink i640 Wireless Telephone
Link Wireless Telephone
Link and NetLink PTBxxx Wireless Telephones
THE INFORMATION PROVIDED IN THE SPECTRALINK TECHNICAL BULLETIN IS PROVIDED "AS IS" WITHOUT WARRANTY OF ANY KIND. NO
OBLIGATION OR LIABILITY WILL ARISE OUT OF, SPECTRALINK RENDERING TECHNICAL OR OTHER ADVICE OR SERVICE IN CONNECTION HEREWITH.
SpectraLink Corporation • 5755 Central Avenue • Boulder, Colorado 80301 • 303.440.5330 • Fax 303.440.5331
10/11/2005
Any
Any
Link WTS, NetLink Wireless Telephones
General
Survivable drop test height
5 feet
10 feet
24 feet
24 feet
24 feet
Technical Bulletin 05-10
Originator:
Jason Malone
Approvers:
Status:
Revision:
A
