Sample generic file: filename is SIP_allusers.cfg
PROXY1_ADDR = 10.1.1.0
PROXY1_DOMAIN = slnkengr.com
PROXY2_ADDR = 10.15.10.2:5060
PROXY2_TYPE = Asterisk
PROXY2_DOMAIN = asterisk
PROXY2_KEYPRESS_INFO = enable
PROXY2_KEYPRESS_2833 = disable
PROXY2_HOLD_IP0 = disable
PROXY2_MAIL_SUBSCR = sip:1001@10.15.10.2
PROXY2_MAIL_NOTIFY = sip:asterisk@10.15.10.2
PROXY2_MAIL_ACCESS = 7999
FAVORITE = 3001;John Doe"
FAVORITE = 799;helpdesk
FAVORITE = *98;"Forward all"
Sample specific file: filename is SIP_1002.cfg
# Line definitions
LINE1
LINE1_PROXY
LINE1_CALLID
LINE2
LINE2_PROXY
LINE2_CALLID
FAVORITE
LINE3
LINE3_PROXY
LINE3_CALLID
6.2

The Handset Display

When active, the handset screen has six rows that display information in this format:
Row 1 displays signal, battery and voicemail icons and line number icons. Row 2
displays the line number of the line for which information is being displayed. Row 3
displays instructions where needed. Two calls are permitted on each line. Row 4
displays information for call one and row 5 displays information for call two. Row 5
is also used to provide dialing aid for call one. Row 6 displays available softkeys.
6.3

Using the SIP Handset

By default, the username assigned to the line one appearance is displayed on the
standby screen.
The line one appearance username is also used as a caller ID for the PTT
application.
View the five line appearances by pressing the
extension number of the first four lines are displayed. Press the
PN: 72-1089-02-E.doc
Configuration and Administration—NetLink e340/h340/i640 Wireless Telephone
= 1002
= 2
= John Doe
= 1002
= 2
= John Doe
= 3555;BOB
= 1025
= 2
= John Doe addnl line
Row # Information provided
1 Icons
2 Line number
3 Instructions
4 Call one info
5 Call two info or dial aids
6 Softkeys
LINE key. The line number and
LINE
with SIP
key again to
