SpectraLink NetLink e340 Supplementary Manual

3com wireless lan mobility system
Hide thumbs Also See for NetLink e340:

Advertisement

Quick Links

Download this manual See also: Configuration Manual, User Manual
3
Com Wireless LAN Mobility System
C
onfiguration and Deployment Guide
SpectraLink's Voice Interoperability for Enterprise Wireless (VIEW) Certification
Program is designed to ensure interoperability and high performance between NetLink
Wireless Telephones and WLAN infrastructure products. The products listed below
have been thoroughly tested in SpectraLink's lab and have passed VIEW Certification.
This document details how to configure the 3Com Wireless LAN Mobility System with
NetLink Wireless Telephones.
Certified Product Summary
VIEW Partner:
Approved products:
RF technology:
Radio:
Security :
Switch/AP software version tested:
NetLink handset models tested:
NetLink handset software tested:
NetLink radio mode:
Maximum telephone calls per AP:
Recommended network topology:
† Denotes products directly used in Certification Testing

Service Information

The AP must support SpectraLink Voice Priority (SVP). Contact your AP
vendor if you need to upgrade the AP software.
If you encounter difficulties or have questions regarding the configuration process of the
Mobility System, please contact 3Com Corporation at 1-800-NET-3Com in the U.S., or
to find a local support telephone number at 3Com's Global Support site, please visit:
http://www.3com.com/.
Copyright © 2005 to 2007 SpectraLink Corporation. All rights reserved.
PN: 72-9966-00-D.doc
3Com:
www.3com.com
WLAN Switches
Managed Access Point
WX4400
3750 †
WX1200 †
WXR100
802.11b/g
2.4 – 2.484 GHz
WPA-PSK and WPA2-PSK
Release 4.0.15
e340/h340/i640
8000 Series
89.119
122.010 or greater
802.11b
802.11b
10
Switched Ethernet (required)
Page 1

Advertisement

loading
Need help?

Need help?

Do you have a question about the NetLink e340 and is the answer not in the manual?

Questions and answers

Related Manuals for SpectraLink NetLink e340

Summary of Contents for SpectraLink NetLink e340

  • Page 1: Service Information

    Program is designed to ensure interoperability and high performance between NetLink Wireless Telephones and WLAN infrastructure products. The products listed below have been thoroughly tested in SpectraLink’s lab and have passed VIEW Certification. This document details how to configure the 3Com Wireless LAN Mobility System with NetLink Wireless Telephones.

  • Page 2: Network Topology

    1. You cannot have WPA-PSK and WPA2-PSK configured on handsets simultaneously within the same ESSID. The phones will not check in. 2. You must disable IGMP snooping when running SpectraLink’s SRP protocol (used with NetLink Telephony Gateways). SRP uses multicast packets to check-in which are not forwarded through the Wireless Switch when IGMP snooping is enabled.
  • Page 3 Adequate coverage for a NetLink Wireless Telephone can be determined by using the Site Survey mode on the Wireless Telephone that displays dB levels and channel when the phones are in range of an access point (within approximately a - 60dBM signal strength radius).
  • Page 4 Access Point Setup and Configuration Installing software 3Com Mobility System firmware cannot be downloaded from the SpectraLink Web site; therefore, you must use the software that was shipped with your product, or contact 3Com for the latest software release. Command, comment, and screen text key In the sections below you will find commands, comments, prompts, system responses, or other screen-displayed information involved in the configuration process.
  • Page 5 set service-profile vowlan-wpa2 cipher-tkip disable set service-profile vowlan-wpa2 cipher-ccmp enable set service-profile vowlan-wpa2 auth-dot1x disable set service-profile vowlan-wpa2 auth-psk enable set service-profile vowlan-wpa2 psk-raw <256-bit passkey> WPA-PSK Assume you are creating service profile “vowlan-wpa” to define the ESSID “phones”, as well as a WPA-PSK security policy.
  • Page 6 Network topology and access point hardware configuration The network topology and access point hardware configuration can be configured using the Mobility System Software. Please refer to the 3Com Corporation Mobility System Software Configuration Quick Start Guide or the 3Com Wireless Switch and Controller Installation and Basic Configuration Guide for more information.
  • Page 7 The following commands are needed to enable SpectraLink Voice Priority (SVP) via access control list (ACL): This rule places all IP protocol 119 (SVP) traffic on CoS queue 7 (SVP support): set security acl ip SVP permit cos 7 119 0.0.0.0 255.255.255.255...
  • Page 8 If you have a previous mobility-domain configuration that is no longer valid, you must clear the existing mobility-domain before a new one can be defined. clear mobility-domain # system will respond: success: change accepted display mobility-domain config # system will respond: there is no mobility domain configuration To check the mobility domain, use the following command: display mobility-domain...
  • Page 9 Configuration File (For Reference Only) The following configuration file was used during VIEW Certification testing. The configuration below includes all configuration attributes, including defaults. Use the command display configuration all default configuration values, use the command # General Configuration set ip dns domain 3com.com set ip dns enable set log console enable severity error set log session disable severity info...
  • Page 10 # for WPA this should be enabled set service-profile VoWLAN-WPA cipher-wep104 disable set service-profile VoWLAN-WPA cipher-wep40 disable set service-profile VoWLAN-WPA auth-dot1x disable set service-profile VoWLAN-WPA auth-psk enable set service-profile VoWLAN-WPA beacon enable set service-profile VoWLAN-WPA ssid-type crypto set service-profile VoWLAN-WPA auth-fallthru last-resort set service-profile VoWLAN-WPA psk-raw <256-bit passkey>...
  • Page 11 set radio-profile default max-rx-lifetime 2000 set radio-profile default rts-threshold 2346 set radio-profile default short-retry 5 set radio-profile default long-retry 5 set radio-profile default frag-threshold 2346 set radio-profile default preamble-length short set radio-profile default auto-tune channel-config enable set radio-profile default auto-tune power-config disable set radio-profile default auto-tune channel-interval 3600 set radio-profile default auto-tune power-interval 600 set radio-profile default auto-tune channel-holddown 300...
  • Page 12 set ap 2 radio 2 channel 36 tx-power 17 radio-profile default mode disable set ap 2 radio 2 auto-tune max-power default min-client-rate 24 max-retransmissions 10 set arp agingtime 1200 set ip https server disable set ip snmp server disable set ip ssh server enable set ip ssh 22 set ip telnet server enable set ip telnet 23...
  • Page 13 set igmp querier disable vlan 1 set igmp mrsol disable vlan 1 set igmp version 2 vlan 1 set igmp mrsol mrsi 30 vlan 1 set igmp qi 125 vlan 1 set igmp oqi 255 vlan 1 set igmp qri 100 vlan 1 set igmp lmqi 10 vlan 1 set igmp rv 2 vlan 1 set igmp mrouter port 3 disable...
