SpectraLink Corporation
2.4
System Diagram
The following diagram shows the SpectraLink components residing on a network
with APs and wireless LAN Ethernet Switch.
access point
Wireless
Telephones
access point
optional
Wireless
POS
Supplied by
SpectraLink
PN: 72-1089-02-E.doc
Configuration and Administration—NetLink e340/h340/i640 Wireless Telephone
Handset code
SIP config
TFTP server
Ethernet switch
SIP Server(s)
SIP proxy or SIP B2BUA
Ethernet cable
Phone cable
NetLink SVP Server
internet
Optional SIP
Phones
with SIP
Page 8
