SpectraLink Corporation
PBX via the proxy server if the user selects
defined Preferences section.
Audio features
Speakerphone features are not available on the e340/h340/i640 handset.
2.8

Startup Sequence

The NetLink Wireless Telephone goes through an initialization sequence at startup.
The line icons 1-9 display and count down as the handset steps through this
sequence. This is usually very rapid. If there is difficulty at any step that prevents
initialization from continuing, an error message will display and the related icon(s)
will stay on. Please see the error table at the back of this document for instructions
on how to handle error messages that occur during initialization.
Icon
The icon(s) shown in bold turns off when:
123456789
The handset has located and authenticated and associated with at least one AP, and is proceeding to
bring up higher-layer networking functions.
12345678
The handset is either configured for Static IP, or if configured for DHCP, the DHCP discovery process
has started.
1234567
If DHCP is configured, a DHCP response was received which contains a good DNS server
configuration.
123456
Note: Only valid on non-SRP protocol. Indicates one of the following:
Static IP configuration, or
NetLink SVP Server address found in DHCP response, or
NetLink SVP Server address found via DNS lookup.
12345
All networking functions are complete (notably, DHCP), and the handset is proceeding with
establishing the SRP link to the NetLink SVP Server.
1234
The SRP link is established; all network stack initialization is complete, proceeding with application-
specific initialization.
123
SIP application startup. Icon 3 is extinguished if a generic SIP config file is found.
12
Icon 2 is extinguished if a handset specific SIP config file is found.
(no icons)
Handset is attempting to register each of the specified line contacts.
Registering
(no icons)
Handset has registered with at least one contact on one proxy server. Initialization is complete. The
EXT. XXXXX
handset is in standby mode ready to receive and place calls. The line one contact is displayed.
During the last three steps of this process, the handset contacts the SIP TFTP server
and downloads general information about the proxy server(s), downloads specific
PN: 72-1089-02-E.doc
Configuration and Administration—NetLink e340/h340/i640 Wireless Telephone
PBX
cadence described in the User-
with SIP
Page 13
