Regardless of the mode in which the handset is operating, the following components
are required and must be configured as part of the SIP system:
Phone IP The IP address of the handset. This is automatically assigned if DHCP
is used. If using Static IP configuration, you must obtain a unique IP Address for
each handset from your network administrator.
Proxy Server IP
if Static IP addressing is used. If DHCP is used, the IP address does not need to
be configured but instead is obtained from DHCP option 43.
SVP Server IP
configuration, this is simply the IP address of the NetLink SVP Server. Note that
the NetLink SVP Server must be statically configured to have a permanent IP
address. If DHCP is being used, the handset will try the following, in order: the
DHCP option 151, then a DNS lookup of "SLNKSVP2" if the DHCP options 6
(DNS server) and 15 (Domain Name) are configured.
TFTP Server IP
software images for updating the handsets and contains the handset files. If this
feature is configured (not set to 0.0.0.0 or 255.255.255.255) with either Static IP
configuration or using DHCP option 66 (TFTP server), or the boot server/next
server (siaddr) field, the handset will check for newer software each time it is
powered on or comes back into range of your network. This check takes only a
second and ensures that all handsets in your network are kept up-to-date with the
same version of software.
SIP TFTP Server IP
holds SIP configuration files. In static mode, this parameter must be configured
with an IP address. In DHCP mode, the SIP TFTP server may be specified by
defining the address on the DNS server for the name "siptftp" If this is not
defined, the address specified in option 66 will be used. See Section 5, SIP
Integration Factors.
Default Gateway and Subnet Mask
complex network, which includes routers. Both of these must be configured
either with an IP address under Static IP (not set to 000.000.000.000 or
255.255.255.255) or with DHCP for the handset to contact any network
components on a different subnet. If configured on the DHCP server, use
option 3 for the Default Gateway and option 1 for the Subnet Mask. Contact the
network administrator for the proper settings for the network.
Note that the wireless telephones cannot "roam" across subnets, since they
cannot change IP addresses while operational. Ensure that all APs are
attached to the same subnet for proper operation. The handset can change
subnets if DHCP is enabled and the handset is powered-off then back on
when within range of APs on the new subnet.
Syslog Server IP
section for more information.
PN: 72-1089-02-E.doc
Configuration and Administration—NetLink e340/h340/i640 Wireless Telephone
The IP address of the proxy server. Configure this address only
The IP address of the NetLink SVP Server. If using Static IP
The IP address of a TFTP server on your network, which holds
The IP address of a TFTP server on your network, which
Used to identify subnets, when using a
The IP address of the syslog server. See the Diagnostic Tools
with SIP
