11.3 Handset Status Messages

NetLink Wireless Telephone status messages provide information about the NetLink
e340/h340/i640 Wireless Telephone's communication with the AP and host
telephone system. The following table summarizes, in alphabetical order, the status
messages.
Message Description
3 chirps (audio) Handset is not able to communicate with the
best AP, probably because that AP has no
bandwidth available.
Address Mismatch Handset software download files are
incorrect or corrupted.
ASSERT xxx c The handset has detected a fault from which
Line yyy it cannot recover.
Assoc Failed x...x = AP MAC address.
xxxxxxxxxxxx Handset association was refused by AP;
displays MAC of failing AP.
Assoc Timeout x...x = AP MAC address.
xxxxxxxxxxxx Handset did not receive association
response from AP; displays MAC of failing
AP.
Auth Failed x...x = AP MAC address.
xxxxxxxxxxxx Handset authentication was refused by AP;
displays MAC of failing AP.
Auth Timeout x...x = AP MAC address.
xxxxxxxxxxxx Handset did not receive authentication
response from AP; displays MAC of failing
AP.
Bad Code Type xx xx, yy = software license types.
Expected Code Type yy Handset software does not match current
handset license selection.
Bad Config Some needed configuration parameter has
not been set.
Bad ESSID The handset is configured for "static ESSID"
(as opposed to "Learn once" or "Learn
always"), and no ESS ID has been entered.
Bad Phintl File Handset software download files are
incorrect or corrupted.
PN: 72-1089-02-E.doc
Configuration and Administration—NetLink e340/h340/i640 Wireless Telephone
Action
None. This is only a warning, the call will
hand off to the best AP once it becomes
available.
Download new software from the
Software
SpectraLink website per
Maintenance
.
Record the error code so it can be
reported.
Turn the handset off then on again.
If error persists, try registering a different
handset to this telephone port.
If error still persists, contact SpectraLink
Technical Support and report the error.
Check handset and AP security settings.
Configuration
Ensure AP is configured per
Note
.
Try another AP.
Check handset and AP security settings.
Configuration
Ensure AP is configured per
Note
.
Try another AP.
Check handset and AP security settings.
Configuration
Ensure AP is configured per
Note .
Try another AP.
Check handset and AP security settings.
Ensure AP is configured per Configuration
Note
.
Try another AP.
Download new software from the
Software
SpectraLink website per
Maintenance .
Check all required handset configuration
parameters for valid settings.
Enter an ESSID in the configuration
settings or change to one of the "Learn"
modes.
Download new software from the
Software
SpectraLink website per
Maintenance .
with SIP
