Successful Handoff
Security Error
Call Start
Call End
Audio stats
Audio error threshold exceeded
(Sent if payloads missed rate or payloads late
rate exceeds 2%, or if the average jitter is over 2
msec)
Radio stats
Radio error threshold exceeded
(Sent if TX drop rate exceeds 2% or TX or RX
retry rate exceeds 5%)
Messages are formatted like the following example:
Jan 1 00:01:26.72 0090.7a02.2a1b (172.16.0.46) [001a] RStat: AP 00:40:96:48:1D:0C (-56 dBm),
Sent 783523, Recvd 791342, MSnt 245, MRcd 5674, BSnt 43, BRcd 10783, TX drop 43 (0.0%), TX retry
578 (1.2%), RX retry 1217 (1.6%)
PN: 72-1089-02-E.doc
Configuration and Administration—NetLink e340/h340/i640 Wireless Telephone
New AP MAC
New AP signal strength
Old AP MAC
Old AP signal strength
Reason for handoff
Other candidate APs:
MAC
Signal strength
Reason not used
AP MAC
AP signal strength
Security mode
Error details (mode dependent)
Call type (telephony, OAI, PTT)
AP MAC
AP signal strength
AP MAC
AP signal strength
AP MAC
AP signal strength
Payload size (in msec)
Payloads sent
Payloads received
Payloads missed (not received)
Payloads missed rate (over last 5 seconds)
Payloads late
Payloads late rate (over last 5 seconds)
Average jitter
Same as audio stats
AP MAC
AP signal strength
Directed packets sent
Directed packets received
Multicast packets sent
Multicast packets received
Broadcast packets sent
Broadcast packets received
TX dropped count
TX drop rate (over last 5 seconds)
TX retry count
TX retry rate (over last 5 seconds)
RX retry count
RX retry rate (over last 5 seconds)
Same as radio stats
with SIP
