beacon interval of 200 ms. The third has a signal strength of –56 dBm, is configured
on channel 11 with a beacon interval of 100 ms.
When the any ESSID mode is selected, the summary display contains the first six
characters of the AP's ESSID instead of the beacon interval as in the example below.
In detail mode the display would appear as follows. The left/right arrow keys will
move between AP indices.
Where:
• i = index of selected AP (value will be from 0 to 3 inclusive)
• bbbbbb = the last three octets of the BSSID for a discovered AP
• sn = signal strength in –dBm
• ch = channel
• bcn = beacon interval
• eeeeeeeeeee = SSID (up to first 11 characters)
• DGHI = standards supported
• rrrrrrrr = rates supported. Basic rates will have a "b" following the rate
• + – more rates are supported than those displayed
• xxxx = WMM or UPSD if those QoS methods are supported
• mmm = security mode
• G:gggg = group key security
• P:pppp = pairwise key security
• Any/MyID = softkey to toggle between "single SSID" and "any SSID" modes
• Detl/Smry = softkey to toggle between the multiple AP display (summary), and
the single AP display (detail)
