With CDP compatibility enabled, your device can receive and recognize CDP packets from a Cisco IP
phone and respond with CDP packets, which carry the voice VLAN configuration TLVs. The voice traffic is
confined in the configured voice VLAN, and differentiated from other types of traffic.
CDP-compatible LLDP operates in one of the following modes:
TxRx: CDP packets can be transmitted and received.

Disable: CDP packets cannot be transmitted or received.


Protocols and standards

IEEE 802.1AB-2005, Station and Media Access Control Connectivity Discovery

ANSI/TIA-1057, Link Layer Discovery Protocol for Media Endpoint Devices


Configuring LLDP

LLDP configuration task list

Perform the tasks in
LLDP configuration task list
1.
Task
Enabling LLDP on ports
Configuring LLDP settings
on ports
Configuring global LLDP
setup
Displaying LLDP
information for a port
1 to configure LLDP:
Remarks
Optional
By default, LLDP is enabled on ports.
Make sure that LLDP is also enabled globally, because LLDP can work on a port
only when it is enabled both globally and on the port.
Optional
LLDP settings include LLDP operating mode, packet encapsulation, CDP
compatibility, device information polling, trapping, and advertised TLVs.
By default,

The LLDP operating mode is TxRx.

The encapsulation format is Ethernet II.

CDP compatibility is disabled.

Device information polling and trapping are disabled.

All TLVs except the Location Identification TLV are advertised.
Required
By default, global LLDP is disabled.
To enable LLDP to work on a port, enable LLDP both globally and on the port.
Optional
You can display the local LLDP information, neighbor information, statistics, and
status information of a port, where

The local LLDP information refers to the TLVs to be advertised by the local
device to neighbors.

The neighbor information refers to the TLVs received from neighbors.
