Icom IC-F7000 Instruction Manual page 9

D D Frequency indication
ALE-U
q
RX
w
e
r
t
P.AMP
y
q OPERATING MODE INDICATOR
Shows the selected operating mode.
• "USB," "LSB," "AM," "CW," "FSK," "AFSK," "ALE-U,"
"ALE-L" or "EMAIL" appears depending on operating
mode and setting. (Selectable mode is USB only for AUS
version.)
w TRANSMIT/RECEIVE INDICATOR
➥ "RX" appears when signals are received or the
squelch is open.
➥ "TX" appears during transmit when the split func-
tion is OFF.
e TRANSMIT/RECEIVE FREQUENCY INDICATOR
Shows the transmit/receive frequency of the chan-
nel. Receive frequency is displayed during recep-
tion, transmit frequency is displayed during trans-
mission when the split function is OFF.
r TRANSMIT INDICATOR
"TX" appears during transmit when the split function
is ON.
TX-12.163.5
-------- 12:34 ========
u
t TRANSMIT FREQUENCY INDICATOR
y PREAMPLIFIER INDICATOR
u S-METER INDICATOR
i TRANSMIT POWER INDICATOR
o MUTE INDICATOR
!0 TIME INDICATOR
PANEL DESCRIPTION
HI
S
Shows the transmit frequency when the split func-
tion is ON.
"P.AMP" appears when the Preamp function is ON.
Shows the receiving signal strength during receive.
Shows the selected transmit output power.
• "HI," "MID," "LO" appears when the transmit power is
set to high power, middle power, low power respectively.
➥ "V" appears when the voice mute is selected.
➥ "L" appears when the signal level mute is se-
lected.
➥ "S" appears when the call mute is selected.
Shows time data.
1
i
o
!0
1
