Options - Icom IC-F7000 Instruction Manual

AT-130/E
AUTOMATIC ANTENNA TUNER
Matches the transceiver to a long wire
antenna with a minimum of insertion loss.
MN-100
ANTENNA MATCHER
Match the transceiver to a dipole an-
tenna. Covers all HF bands from 1.5 to
30 MHz. 8 m (26.2 ft.) × 2 antenna wires
come attached.
RC-26
REMOTE CONTROLLER
Same as that supplied remote controller
with the transceiver. Mounting bracket is
supplied with the controller.
Recommended Automatic tuning antenna, AT230 from Moonraker Australia Pty. Limited
The AT230 is a 2.6 m length mobile whip antenna with automatic tuning function. The antenna
matches 2–30 MHz continuously. Use the optional OPC-1287 cable for use with the IC-F7000.
Ask your dealer for details.
AT-140
AUTOMATIC ANTENNA TUNER
Antenna and control cable receptacles
for easy installation and tuner through
function are available.
MN-100L
ANTENNA MATCHER
match the transceiver to a long wire an-
tenna. Covers all HF bands from 1.5 to
30 MHz. 15 m (49.2 ft.) × 1 antenna wire
comes attached.
SP-25
EXTERNAL SPEAKER
Same as that supplied with the IC-F7000.
Mounting bracket is supplied with the
speaker.
Max. AF input/impedance: 5 W/4 Ω
HM-155
HAND MICROPHONE
Same as supplied with the IC-F7000.
AH-2b
ANTENNA ELEMENT
A 2.5 m long antenna element for mobile
operation with the AT-130/E or AT-140.

OPTIONS

PS-60
DC POWER SUPPLY
Provides 13.6 V DC (30 A) output from
an AC outlet.
AH-710
FOLDED DIPOLE ANTENNA
Covers from 1.9 to 30 MHz band. Has an
SO-239 connector. Easy to assemble
(non-kink construction).
OPC-1286/N
SHIELDED CONTROL CABLE
Shielded control cable protects the trans-
ceiver from RF feedback and extends the
separation between AT-140 and trans-
ceiver up to 10 m.
OPC-1287
SHIELDED CONTROL CABLE
Shielded control cable protects the trans-
ceiver from RF feedback and extends the
separation between AT230 and trans-
ceiver up to 5 m.
