Closing the System

Before closing the system, verify that all connectors and boards are
properly installed and firmly seated.

Closing the Subchassis and Electronics Bay

As you close the subchassis and electronics bay, carefully observe the
internal components to ensure that you do not pinch or twist any of the
cables or components.
To Close the Subchassis and Electronics Bay
Verify that all internal components are fully installed and secured.
1.
Press down on the tab on the top of the electronics bay to release it and
2.
swing it closed.
3.
Attach any cables to the electronics bay components.
Press down on the tab at the top of the subchassis to free it and swing it
4.
closed.
Secure the subchassis with the two screws you removed earlier.
5.
6.
If necessary, reinstall the foam bracketing for the fans in the
subchassis and reinstall the fans.
Reinstall the foam over the subchassis and electronics bay.
7.
Replace the access cover and power up the system.
8.
Closing the System
7
