Sensor Data Record Viewer
The sensor data record (SDR) viewer lets you view the records retrieved
from the SDR repository. Options available through the SDR viewer are:
•
View all SDR records
•
View SDR entries by SDR type
•
View SDR summary information
•
Set SDR display mode to either Hex or verbose mode
•
Close the SDR viewer
•
Exit the EMP console
SDR Viewer Menu Options
The SDR viewer menu bar contains the following:
•
File
• Close: Closes the SDR viewer.
• Exit: Exits the EMP console.
•
View
• Display all Records: Displays all records from the SDRR.
• SDR Type: Displays the records of a particular SDR type.
Select an SDR type from a pop-up menu that displays all of
the SDR types available for the hardware.
• SDR Info: Displays the SDR summary information.
•
Settings: Lets you change operating parameters for the SDR
viewer. This menu displays the following suboption:
• Display HEX/Verbose: Toggles between HEX mode and
interpreted mode of display.
•
Window: Gives options for displaying currently open windows.
•
Help: Provides version information for the SDR viewer and
provides help topics on the EMP console.
Emergency Management Port Console 143
