88 Maintaining and Troubleshooting the Gateway ALR 9200 Server
Table 13: Advanced Menu (Continued)
Field
Large Disk Access Mode LBA
Pause Before Boot
Advanced Chipset
Control

PCI Configuration Submenu

The PCI Configuration Menu contains selections that access other
submenus.

PCI Device, Embedded SCSI Submenu

This submenu provides three fields that allow you to control certain
characteristics of the embedded SCSI controllers. Table 14 lists the fields
and options.
Table 14: PCI Device, Embedded SCSI Submenu
Field Options
Option ROM Scan Enabled
Disabled
Enable Master Disabled
Enabled
Latency Timer Default
0020h
0040h
0060h
0080h
00A0h
00C0h
00E0h
Options Description
Applies to IDE drives only; refers to the method
CHS used to access the drive.
Most operating systems use logical block
addressing (LBA); some use cylinder head sector
(CHS). To verify the correct method, consult the
operating system documentation.
Enabled Enables a five-second pause before booting the
Disabled operating system.
N/A Enters submenu.
Description
Enables the option ROM scan of the
selected device.
Enables the selected device as a PCI bus
master.
Defines the minimum guaranteed time, in
units of PCI bus clocks, that a device can
be master on a PCI bus. Typically, option
ROM code overwrites the value set by the
BIOS.
