Table 41: Extended VGA Modes (Continued)
Colors
Mode Bits / (#/ Palette
in Hex Pixel Size)
67 16 32K
67 16 32K
68 16 32K
(interlaced)
68 16 32K
68 16 32K
68 16 32K
68 16 32K
68 16 32K
6C 8 16/256K
(interlaced)
6D 8 256/256K
(interlaced)
6D 8 256/256K
6D 8 256/256K
6D 8 256/256K
6E 16 32K
6E 16 32K
6E 16 32K
6E 16 32K
71 24 16M
71 24 16M
71 24 16M
71 24 16M
71 24 16M
74 16 64K
(interlaced)
74 16 64K
74 16 64K
74 16 64K
74 16 64K
74 16 64K
78 16 32K
78 24 16M
78 24 16M
78 24 16M
78 24 16M
78 24 16M
7B 8 256/256K
(interlaced)
Pixel Horiz.
Freq. Freq.
Resolution (MHz) (kHz)
800 X 600 56.25 53.7
800 X 600 68.2 63.6
1024 X 768 44.9 35.5
1024 X 768 65 48.3
1024 X 768 75 56
1024 X 768 78.7 60
1024 X 768 94.5 68.3
1024 X 768 113.3 81.4
1280 X 1024 75 48
1280 X 1024 75 48
1280 X 1024 108 65
1280 X 1024 135 80
1280 X 1024 157.5 91
1152 X 864 94.5 63.9
1152 X 864 108 67.5
1152 X 864 121.5 76.7
1152 X 864 143.5 91.5
640 X 480 25 31.5
640 X 480 31.5 37.9
640 X 480 31.5 37.5
640 X 480 36 43.3
640 X 480 43.2 50.9
1024 X 768 44.9 35.5
1024 X 768 65 48.3
1024 X 768 75 56
1024 X 768 78.7 60
1024 X 768 94.5 68.3
1024 X 768 113.3 81.4
800 X 600 36 35.2
800 X 600 40 37.8
800 X 600 50 48.1
800 X 600 49.5 46.9
800 X 600 56.25 53.7
800 X 600 68.2 63.6
1600 X 1200 135 62.5
Vert. Memory
Freq.
(Hz)
85 1MB
100 1MB
43 2MB
60 2MB
70 2MB
75 2MB
85 2MB
100 2MB
43 1MB
43 2MB
60 2MB
75 2MB
85 2MB
70 2MB
75 2MB
85 2MB
100 2MB
60 1MB
72 1MB
75 1MB
85 1MB
100 1MB
43 2MB
60 2MB
70 2MB
75 2MB
85 2MB
100 2MB
56 1MB
60 2MB
72 2MB
75 2MB
85 2MB
100 2MB
48 2MB
Video Modes 185
