118 Maintaining and Troubleshooting the Gateway ALR 9200 Server

System Event Log Viewer Add-in

Clicking on the system event log (SEL) add-in task brings up the SEL
viewer add-in, which allows you to:
•
Examine SEL records via the BMC in hex or verbose mode
•
Examine SEL records by sensor or event type in hex or verbose
mode
•
Examine SEL records from a previously stored binary file in hex
or verbose mode
•
Save SEL records to a file in either text or binary form
•
Clear SEL entries from the non-volatile storage area
The SEL viewer main window provides access to features of the add-in.
Each option included on the main menu supports an accelerator key.
Accelerator keys are indicated by an underlined letter in the text listing the
option. The main window includes support to display the following
information for each SEL entry: record identifier, event type, time stamp
information, generator identifier, EMV revision, sensor type, sensor
number, and event description.
Figure 31 shows the SEL viewer main window. Table 26 lists the window's
menus and options.
