112 Maintaining and Troubleshooting the Gateway ALR 9200 Server
Resource Configuration Add-in
Window
The resource configuration add-in (RCA) window provides three major
functions:
•
Creates representations of devices that cannot be discovered by the
system (ISA boards)
•
Modifies the contents of the system by adding and removing
devices
•
Modifies the resources used by devices

Using the RCA Window

You can use the RCA window to define or add an ISA board by clicking on
the appropriate button. To remove an ISA board, highlight the board in the
Devices section of the screen before clicking on the button. You can add
only as many ISA boards as there are ISA slots available.
From the SSU main window, launch the RCA by selecting the
1.
Resources task under the RCA heading in the task box.
2. When the RCA window appears, it displays messages similar to the
following:
Baseboard: System Board
PCI Card: Bus 00 dev 00 -– Host Processor Bridge
PCI Card: Bus 00 dev 0D –- Multifunction Controller
PCI Card: Bus 00 dev 0F –- Ethernet Controller
PCI Card: Bus 00 dev 12 –- Multifunction Controller
PCI Card: Bus 00 dev 14 –- VGA Controller
To Use the RCA Window
