Note:
The bezel key lock must be
in the open position before
reinstalling the access cover.
8 Maintaining and Troubleshooting the Gateway ALR 9200 Server

Installing the Access Cover

Be careful to avoid pinching any internal cables in the access cover when
closing the system.
To Replace the Access Cover
Before replacing the access cover, check that you have not left loose
1.
tools or parts inside the system.
Check that cables, expansion cards, foam pad, and other components
2.
are properly installed.
Position the cover over the chassis so that the rows of tabs align with
3.
slots in the chassis. While pressing inward, slide the cover toward the
front of the system until the tabs on the cover firmly engage in the
chassis.
Attach the cover to the chassis with the three screws you removed
4.
earlier, and tighten them firmly.
Connect all external cables and the power cords to the system.
5.

Installing the Front Door

To replace the front door, insert the hinges into the slots on the front of the
chassis and close the door. Secure it by turning the bezel keylock to the
second locked position. The first position allows you to open the front door
and locks the side access panel. The fully locked position prevents all
access to the system controls by locking both the access panel and the bezel
door.
