EMP Access Modes: Choose either disabled, pre-boot, or always active,
depending on the type of EMP access needed. Table 29 on page 132 and
Table 30 on page 132 list what is available with a given setting.
EMP Restricted Mode Access: Set restricted mode to either enabled or
disabled. In enabled mode, the EMP console server control options, Power
On/Off and Reset, are NOT available. In disabled mode, these options are
available.
EMP Direct Connect/Modem Mode: Select if a null
Direct Connect
modem serial cable directly connects the server COM2 port to the EMP
console client machine. If they are connected via a modem, select
Modem
Mode .
Console Redirection Submenu
To use the EMP, you must set the following options exactly as noted.
COM Port Address: Select 2F8. This is the COM2 port that the EMP must
use. The IRQ# setting is automatically assigned with the correct number
based on the COM port address choice.
Baud Rate: Select 19.2k.
Console Type: Choose PC ANSI.
Flow Control: Choose CTS/RTS + CD.

Main EMP Console Window

The main EMP console window provides a graphical user interface (GUI)
to access server control operations and to launch the management plug-ins.
A menu and tool bar at the top of the GUI provide options to initiate plug-
ins and other support features. A status bar at the bottom displays
connection information like server name, line status, and mode.
