Gateway ALR 9200 Maintaining And Troubleshooting page 133

Figure 32: SDR Manager Main Window
Table 27: SDR Manager Menus and Options
Menu Options
File Open FRU: Opens FRU data from a previously saved file
Save SDR: Saves SDR data to a file in binary raw or verbose text format
Exit: Quits the SDR Manager
View SDR Info: Displays SDR information as returned by the GetSDRInfo interface
of the BMC
All Records: Displays all records in the SDR repository
By Record: Displays all records in the SDR repository, sorted by record type
Settings Display HEX: Displays SDR records in Hex format
Display Verbose: Displays SDR records in verbose format
Output Text: Saves SDR data in verbose format
Output Binary: Saves SDR data in binary format
Help About: Displays SDR Manager version information
Sensor Data Record Manager Add-In 121
