176 Maintaining and Troubleshooting the Gateway ALR 9200 Server

Specifications

System Specifications

The following specifications are for the standard configuration; your
system may contain optional equipment. All specifications are subject to
change.
Summary
Dimensions
Processor
Processor speed
Processor upgrade
Cache subsystem
RAM
BIOS
IDE interfaces
Diskette drive
I/O Ports
Mouse/Keyboard
ISA/PCI Expansion
Slots
Certification
The system supports up to four Pentium II Xeon
processors running at 400 or 450 MHz. These
processors fit into the slot 2 connectors on the system
board. The system also supports seven expansion
slots, six LVD SCA SCSI drives, onboard narrow and
onboard wide SCSI controller, and a full complement of
I/O ports
19.0"H x 12.25"W x 25.0"D, 85–100 lbs.
Intel Pentium II Xeon processor
400 or 450 MHz
Slot 2
512 KB, 1 MB, or 2 MB level-2 ECC cache
256-MB standard, 4-GB maximum
Intel
One, supporting two IDE devices
1.44-MB 3.5-inch
Two serial, one parallel, video, mouse, USB, and
keyboard
Yes
Seven PCI/ One ISA (One of the PCI slots and the ISA
slot are shared)
FCC Class A, TUV, CE, CSA, and UL approved
