Offline: Drives that are NOT identified as "bad" may be taken offline if part of a
Striping or Spanning array containing a "bad" drive. These drives do NOT
need to be replaced, however.
S.M.A.R.T. Status: Indicates whether attached hard drive implements Self-
Monitoring Analysis & Reporting Technology to predict drive failure.
Size: Indicates capacity of individual drive.
Location: Shows physical location of drive. Indicates on which IDE channel (1
or 2), and whether drive is Master or Slave on cable. This allows user to
identify drives for removal/replacement.
Mapping: Indicates physical parameters of drive (cylinders, heads, sectors).
Timing: Shows selection of drive timing (directly related to burst speed) based
on type of drive and cable used.
Optional Enclosure Management for SuperSwap
If using your FastTrak100 with an optional Promise Technology SuperSwap
swap drive chassis, the FastCheck array window will also display voltage, fan, and
drive temperature status of the SuperSwap unit when a drive icon is selected as
follows below:
Encl. Type: Identifies SuperSwap and other compatible enclosure models.
H/W Conf: Indicates which enclosure subsystems are being monitored.
Fan Status: Shows operating status of SuperSwap fan and approximate RPM
rate.
Temp: Shows internal temperature of enclosure in both ° F and ° C.
Voltage 5V : Shows approximate voltage status of 5V power regulator.
Voltage 12V : Shows approximate voltage status of 12V power regulator.
Refer to the SuperSwap manual for operating parameters.
