Promise Technology FASTtrak100 TX User Manual page 43

Installing Driver with Existing Windows NT 4.0
WARNING: If you plan to move your boot drive to a mirrored RAID 1
FastTrak array, hard drives should NOT be connected to the
FastTrak100
procedure. The FastTrak100 drivers must be loaded on the system
hard drive (running under the existing hard drive controller) before any hard drives
are connected to the FastTrak100 controller card.
1. Choose "Settings" from the "Start " menu.
2. Choose "Control Panel" from the "Settings" menu.
3. Double-click on the "SCSI Adapters" icon, which generates the "SCSI
Adapters" dialog box.
4. Choose "Drivers," and then press "Add."
5. In the "Install Drivers" dialog box, press "Have Disk... "
6. When the "Ins tall From Disk" appears, insert the "FastTrak100 Driver"
diskette in drive A:.
7. Type "A:\NT4" in the text box window, then choose "OK."
8. When the "Install Driver" dialog box appears, select "WinNT Promise
FastTrak100 TX/LP(tm) Series Controller" and then pre ss "OK."
9. When the "Select SCSI Adapter Option" dialog box appears, press "Install."
10. After a successful installation, the "SCSI Adapter Setup" box will show that
the "WinNT Promise FastTrak100 TX/LP(tm) Series Controller" has been
installed.
11. Power off your system.
12. If moving the boot drive to the FastTrak card, now attach the hard drives,
otherwise reboot.
Removing the Driver from Windows NT 4.x
1. In "Start" Button choose "Control Panel" in "Setup" group.
2. In "Cont rol Panel," select "SCSI Adapter," next choose "Drivers" label
3. Choose "Remove" button.
4. After successful removal, the "SCSI Adapter Setup" box will show that
"WinNT Promise FastTrak100 TX/LP(tm) Series Controller" has been
removed.
FastTrak100 TX/LP™ Series User Manual
controller card before performing the following
39
