Manually Creating an Array

The Define Array <3> option from the Main Menu allows users to begin the process of
manually defining the drive elements and RAID levels for one or multiple disk arrays
attached to FastTrak100. Users will commonly create one or two drive arrays with
FastTrak100, though the card will support a maximum of four arrays
NOTE: For most installations, Promise recommends the <1> Auto Setup for easy
disk array creation.
FastBuild (tm) Utility 1.xx (c) 1995-2001 Promise Technology, Inc.
Array No RAID Mode
Array 1 Stripe
Array 2 — —
Array 3 — —
Array 4 — —
Note: * — Bootable Array
[ ] Up [ ] Down [ESC] Exit [Enter] Select [Space] Change Boot Drive
1. To manually create an array from the Define Array Menu, use the arrow keys to
highlight the array number you wish to define, and press [Enter] to select.
2. The Define Array Definition Menu will next appear that allows drive assignments
to the disk array (see next page).
A user may use a single drive in either striping or spanning mode with FastTrak100.
1
In this rare scenario, the card will create an individual array ID but will offer
conventional controller performance depending on the drive type. At a later time, a
second drive can be added to the array and the array re-created to support RAID 1
mirroring.
FastTrak100 TX/LP™ Series User Manual
[Define Array Menu]
Total Drv
2
— —
— —
— —
[ Keys Available ]
Capacity(MB)
16126
— —
— —
— —
21
1
.
Status
Functional
— —
— —
— —
