Promise Technology FASTtrak100 TX User Manual page 41

Installing Driver in Existing Windows 2000 System
WARNING: If you will be moving the boot drive containing the existing
Windows 2000 operating system to a mirrored RAID 1 array on the
FastTrak100 card, the FastTrak100 driver MUST be loaded to the hard
drive while it is still attached to your existing hard drive controller. Do
not attach this drive or any other hard drive to the FastTrak100 controller card
before completing this step.
NOTE: If you have the FastTrak100 TX4, you will need to go through these steps
twice, since the TX4 appears as 2 controllers to the system.
1. After installing the FastTrak100 card and rebooting your system, Windows
2000 setup will show a "New Hardware Found" dialog box.
Windows 2000, the "PCI RAID Controller" will be displayed. Click on "Next".
2. Choose "Display a list of known drivers for this device so that I can choose
a specific driver". Click on "Next".
3. In the "Install Drivers" dialog box, press "Have disk... "
4. When the "Install From Disk" appears, insert the Promise Technology
FastTrak100 diskette in drive A:.
5. Type "A:\Win2000" in the text box. Press "Enter".
6. Choose "Win2000 Promise Fas tTrak100 TX/LP(tm) Series Controller" from
the list that appears on screen, and then press the "Enter" key.
7. When the "System Settings Change" dialog box appears, remove the floppy
diskette and click on "Yes" to restart the system. Windows 2000 will then
restart for the driver installation to take effect.
Confirming Windows 2000 Installation
1. From Windows 2000, open the Control Panel from "My Computer" followed
by the System icon.
2. Choose the "Hardware" tab, and then click the "Device Manager" tab.
3. Click the "+" in front of "SCSI & RAID Controllers hardware type." The driver
"Win2000 Promise FastTrak100 TX/LP(tm) Series Controller" should appear
(2 listings will appear if you have the FastTrak100 TX4).
FastTrak100 TX/LP™ Series User Manual
37
