Promise Technology FASTtrak100 TX User Manual page 17

Once the arrayed drives have been formatted, proceed to the Installing
7.
Driver chapter on page 30 to install your operating system and/or
FastTrak100 driver.
Creating a Security Array With An Existing Data Drive
NOTE: Under the Security setting, FastTrak100 permits two drives to be used for a
single Mirrored array or four drives to be used for a Mirrored/Striped array in Auto
Setup.
You would use this method if you wish to use a drive that already contains data
and/or is the bootable system drive in your system. You will need another drive of
identical or larger storage capacity.
WARNING: Backup any necessary data before proceeding. Failure to
follow this accepted PC practice could result in data loss.
WARNING: If you wish to include your current bootable drive using
the Windows NT 4.x or Windows 2000 operating system as part of a
bootable Mirrored (RAID 1) array on your FastTrak100, do NOT
connect the hard drive to the FastTrak100 controller yet. You MUST
install the Windows NT4 or 2000 driver software first (see page 30) to
this drive while it is still attached to your existing hard drive controller.
Follow these steps:
Using the Spacebar, choose "Security" under the Optimize Array for
1.
section.
2. Press <Ctrl-Y> keys to Save your selection. The window below will appear.
Do you want the disk image to be duplicated to another? (Yes/No)
Y - Create and Duplicate
N - Create Only
3. Press "Y" for the Create and Duplicate option. The window below will
appear asking you to select the Source drive to use. FastBuild will
copy all data from the Source drive to the Target drive.
Channel:ID
Channel:ID
Channel:ID
FastTrak100 TX/LP™ Series User Manual
Source Disk
Drive Model
Target Disk
Drive Model
[Please Select A Source Disk]
Drive Model
Capacity (MB)
Capacity (MB)
Capacity (MB)
13
