Euphonix Modular I/O Configuration Guide
DD913 8ch AES Out
Technical Specifications
AES/EBU
output format
resolution
sample rate
connector
level
backplane connector
power supply
consumption
dimensions
weight
Installation
transparent, as connector input
24bit
32...96kHz, following the system clock
BNC, 75Ohm, coaxial
0,5 ... 5 Vpp
ref. to DIN41612, 64pin, a+b, male
+5V DC
appr. 100 mA
3RU, 4HP, 175mm depth
~150g
94
Product Data Sheets
2/2
