Euphonix Modular I/O Configuration Guide
Product Data Sheets
1/3
SY982 Sync
Features
• provides sync for modular I/O frames
• internal sync at 44.1, 48, 88.2 or 96kHz
• external sync by AES, word clock or video signal
• lock indication
• redundant sync source with a second SY982
• frame address setting
• word clock output
operation
• turn the front-panel source switch with a small screwdriver to step through all
available sync modes: int 44.1, int 48, int 88.2, int 96, ext video, wclk, aes
Block Diagram
56
