Euphonix Modular I/O Configuration Guide
MM936 MADI In/Out
Features
• interface for MADI coded multichannel audio signals
• MADI receiver and transmitter
• redundant optical input /output connector (1 > 2)
• extended mode (max. 64ch's) and high sampling mode
(max. 32ch's at 96kHz)
• word length 24 bit
• MASTER mode: rack locks to MADI input with
no need for an SY982 Sync module
• full crosspoint matrix configuration/setup by web browser interface
Block Diagram
53
Product Data Sheets
1/3
