Euphonix Modular I/O Configuration Guide
IO94 Stagebox Frame
Technical Specifications
frame size
depth:
rack space
rear-plane space for modules:
weight:
power supplies:
input:
output:
connector:
audio busses
sync/control busses
sync slots:
control buss:
Sample Configuration
to local-side redundant
MADI-over-Fiber I/F
to local-side
LAN-over-Fiber port x2
Blackbox
100TX- (2x)100FX
Redundant Fiber
Media Converter
300mm
3RU
76HP (19 single-width slots)
~5.3kg
dual redundant built-in supplies
100~240VAC 50/60Hz auto-sensing
20 amps at 5vDC
IEC x2
32 stereo busses
four master sync source reserved slots (4HP each) on rear-plane
(may also be used for other modules)
CAN buss
Analog Out 1-16
(15p-DSub x 4)
40
Product Data Sheets
2/3
Mic In 1-48
(RJ45 x 48)
Stagebox frame #1
Preamp Out 1-48:
Analog Split to PA
(15p-DSub x 12)
Stagebox frame #2
