Euphonix Modular I/O Configuration Guide
SD941 4ch SD De/Embedder
CASCADE
-generates a new audio group as selected (TX group) within existing frame
-necessary if a new group should be embedded and if audio in other groups was
-matches the structure which was generated by PACK mode. It is recommended
RX-GR0/RX-GR1 (Receiver Group Select)
-use the table below to select receive group
TX-GR0/TX-GR1 (Transmitter Group Select)
-in PACK or CASCADE mode, use the table below to select the transmit group
-if neither PACK nor CASCADE mode is selected, the transmit group is
group 1
group 2
group 3
group 4
SWAP0
-Swaps receive channels 1 & 2
SWAP1
-Swaps receive channels 3 & 4
EXCHNG
-Swaps receive pairs 1/2 & 3/4
Note: If PACK and CASCADE are not set the embedder will insert into the group
determined by the RX group selection. If RX group 1 is selected and no audio
structure exists at the input, the embedder will automatically switch to PACK
mode and embed into group 1 (AUTO-PACK mode). However, if RX group 2, 3,
or 4 is selected and no audio exists on the selected group at the input, no audio
will be embedded. PACK or CASCADE mode must be selected.
structure. This overwrites all data of this group if it was already
embedded previously.
embedded previously
to use PACK mode for generating audio structure and embedding the
first group before using CASCADE to embed further audio groups.
determined by the receiver group setting (TRANSPARENT mode)
GR0 GR1
- -
ON -
ON
-
ON ON
