AD914 4ch Microphone Input
Features
• 4ch high quality MIC input
• 24bit sigma-delta A/D-converter, sample rate up to 96kHz
• digitally controlled gain 0..+65dB
• max. line input level +20dBu
• pad attenuation -10dB
• floating balanced analog inputs
• electrical isolation between channels
• 48V phantom power
• remote operation via Eucon or web browser interface of up to
256 microphone inputs in a system (64 devices)
Block Diagram
