FC972 Remote FC972 Remote
Technical Specifications
Controller module
Micro controller:
Flash memory:
RAM:
RTC:
OS:
External connectors
LAN (RJ45):
RS232 (Sub-D / 9pin):
CAN (RJ 45):
INIT:
STATUS LED:
Factory settings
IP address:
Subnet mask:
Gateway:
Controller ID:
Frame address:
CAN termination:
General
Back plane connector:
Power supply:
Consumption:
Dimensions:
Weight:
Connector Pin Assignment
RJ45 LAN
Pin # Function
1 Tx +
2 Tx -
3 Rx +
4
5
6 Rx -
7
8
MCF8250 "Coldfire"
8 MByte
16 MByte
DS 1306
eCos
10/100 Mbit/sec Ethernet
Controller serial interface 1
CAN 1.1 (125kBit/sec)
The INIT button is reserved for future applications
The status LED lights yellow for the moment. It is reserved for
future applications
10.110.xxx.yyy where xxx and yyy is factory calculated from the
MAC address of the unit (to avoid address conflicts when installing
systems with multiple frame controllers)
255.255.0.0
No entry
0
0
Off
ref. to DIN41612, 64pin, a+b, male
+5V DC
approx. 300 mA
3RU, 4HP, 175mm depth
~200g
RJ45 CAN
Pin # Function
1 CAN-H
2 CAN-L
3
4 GND
5 GND
6
7
8
