Euphonix Modular I/O Configuration Guide

IO93 Modular Frame

Technical Specifications
frame size
depth:
rack space
front-plane space for modules: 72HP (18 single-width slots)
rear-plane space for modules:
weight:
power supplies:
input:
output:
connector:
audio busses
front-plane
rear-plane:
linking:
sync/control busses
sync slots:
sync linking:
control buss:
420mm
3RU
76HP (19 single-width slots)
~5.3kg
dual redundant PS993
100~240VAC 50/60Hz auto-sensing
16 amps at 5vDC
IEC x2
32 stereo busses
32 stereo busses
via backplane interconnect PC board DIP switches
four master sync source reserved slots (4HP each) on rear-plane
(may also be used for other modules)
front-plane and rear-plane sync busses linked
CAN buss, linked between planes
37
Product Data Sheets
2/3
