Euphonix Modular I/O Configuration Guide
DA921 4ch Analog Line Output
Technical Specifications
resolution
sample rate
dynamic range
THD+N
frequency response
(+/-0.5dB)
crosstalk
max. output level
output impedance
connector
backplane connector
power supply
consumption
dimensions
weight:
Installation
24bit
32...96kHz
112dB (RMS)
117dB (A)
<0.002% @ max. output level
20Hz...20kHz (FS=48kHz)
20Hz...40kHz (FS=96kHz)
>110dB (1kHz)
>105dB (20kHz)
>90dB (40kHz)
+15...+28dBu @ 0dBFS
60 Ohm, floating balanced
XLR, 1-screen, 2-live, 3-return
ref. to DIN41612, 64pin, a+b, male
+5V DC
appr. 650 mA
3RU, 8HP, 175mm depth
~200g
76
Product Data Sheets
2/2
