- Page 1 404 416 Max Air Surfaces Installation Manual Document Revision: A Part Number: 840-11316-01 Release Date: August 2010 Euphonix is Avid. Learn more at www.avid.com...
-
Page 2: Fcc Notice
Operation of this equipment in a residential area is likely to cause harmful interference, in which case the user will be required to correct the interference at personal expense. Euphonix is Avid. Learn more at www.avid.com... - Page 3 This Class A digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations. Cet appareil numérique de la classe A respecté toutes les exigences du Règlement sur le matériel brouilleur du Canada. Euphonix is Avid. Learn more at www.avid.com...
- Page 4 Avid Technology International B.V. Sandyford Industrial Estate Unit 38, Carmanhall Road Dublin 18, Ireland declare under our sole responsibility that the product, erklären, in alleniniger Verantwortung,daß dieses Produkt, déclarons sous notre seule responsabilité que le produit, Euphonix is Avid. Learn more at www.avid.com...
- Page 5 è conforme alla/e seguente/i norma/o documento/i normativo/i. The requirements of the European Council: Safety: Directive 2006/95/EC EN 60065:2002 /A1:2006 EMC: Directive 2004/108/EC EN 55103-1:1996 EN 55103-2:1996 Euphonix is Avid. Learn more at www.avid.com...
- Page 6 Optical connections are located on the rear panel and are typically labeled “Optical” or “SPDIF/ADAT.” The exact location of optical connections is identified more clearly elsewhere in the documentation for the Avid hardware device. Disposal of Waste Equipment by Users in the European Union Euphonix is Avid. Learn more at www.avid.com...
- Page 7 • Reliable earthing — Reliable earthing of rack-mounted equipment should be maintained. Particular attention should be given to supply connections other than direct connections to the branch circuit (for example, use of power strips). Euphonix is Avid. Learn more at www.avid.com...
- Page 8 Explosionsfara vid felaktigt batteribyte. Använd samma batterityp eller en ekvivalent typ som rekommenderas av apparattillverkaren. Kassera använt batteri enligt fabrikantens instruktion. VAROITUS Paristo voi räjähtää, jos se on virheellisesti asennettu. Vaihda paristo ainoastaan laitevalmistajan suosittelemaan tyyppiin. Hävitä käytetty paristo valmistajan ohjeiden mukaisesti. Euphonix is Avid. Learn more at www.avid.com...
-
Page 9: Table Of Contents
Euphonix Max Air Control Surface Manual Table of Contents System Startup Sequence ..................7 Description ........................7 Overview......................7 Self Test Procedure ....................9 Initiating Self Test...................9 Switch and Knob Test ..................9 LED Test .......................10 Fader Test......................10 Display Test ....................11 Memory Test ....................11 Selecting and Adjusting the Onscreen Display ............12 Touchscreen Alignment ..................13... - Page 10 Euphonix Max Air Control Surface Manual List of Figures Typical Console Layout ......................7 CM404 Rear Panel ......................8 CM416 Rear Panel ......................8 Control surface self-test keys ....................9 Changing the CM416 ID ....................15 Side Dimensions .......................17 CM416 Bottom Dimensions .....................17 CM404 Bottom Dimensions .....................18 Max Air Top Dimensions ....................18...
-
Page 11: System Startup Sequence
Euphonix Max Air Control Surface Manual System Startup Sequence See page 21 in the Max Air Operation Manual for the system startup sequence. Description The Max Air Console consists of a configurable number of Control Modules that com- prise the Control Surface. The Max Air Control Surface is the digital control center for all Max Air system components and communicates with them via Ethernet network connections. -
Page 12: Cm404 Rear Panel
Euphonix Max Air Control Surface Manual Rear Panels INTERNAL INTERNAL EXTERNAL EXTERNAL TALKBACK MIC TALKBACK MIC TALKBACK MIC TALKBACK MIC SERVICE SERVICE AC IN 1 AC IN 1 AC IN 2 AC IN 2 SERIAL 1 SERIAL 1 T 5.0 AH... -
Page 13: Self Test Procedure
Euphonix Max Air Control Surface Manual Self Test Procedure The following pages describe the operation of standalone self-test software for the Max Air control modules. The self-test code is designed to be invoked in a module right after power-up and before the Single Board Computer (SBC) downloads code. -
Page 14: Led Test
Euphonix Max Air Control Surface Manual LED Test LED loop This switch cycles through all the LED colors. Color Toggle These switches light all the LEDs of each color: green, red, yellow, orange All LEDS This turns all LEDs on. -
Page 15: Display Test
Euphonix Max Air Control Surface Manual Display Test Clear All Char Up Char Down Char E Char W Enumerate Memory Test ROM Test This test reads the ROM and computes and displays the checksum. The user/tester can match the checksum to a known good checksum (see below) to make sure ROM test is successful. -
Page 16: Selecting And Adjusting The Onscreen Display
Euphonix Max Air Control Surface Manual Selecting and Adjusting the Onscreen Display The Touchscreen image controls are found on the panel behind the Touchscreen. If the image needs adjustment, access press the Menu button and follow the onscreen instructions. Figure 5... -
Page 17: Touchscreen Alignment
Euphonix Max Air Control Surface Manual Touchscreen Alignment The Max Air Touchscreen can be calibrated using the Elo Touchscreen utility. Note that different users may have slightly different ways of touching the screen. If an oper- ator finds they often miss onscreen objects, re-calibrate the touchscreen: Select Control Panel from the Start menu. - Page 18 Euphonix Max Air Control Surface Manual Figure 8 3. Touch Align and follow the onscreen instructions. When asked to touch the targets on the screen, best results are achieved by touching the targets naturally without thinking too much about it. This aligns the touchscreen to an...
-
Page 19: Changing The Id Of A Cm416 Module
Euphonix Max Air Control Surface Manual Changing the ID of a CM416 Module 1. Power cycle the module and then simultaneously press and hold the two lower knobs on the first strip before the module connects to the System PC (you have about 15 seconds). -
Page 20: Technical Specifications
Euphonix Max Air Control Surface Manual Technical Specifications Power 100–240 VAC (RMS), 50/60 Hz Voltage Power Consumption 2 x 50 W per module 3 A Per Input(US 117 V) 1.5 A Per Input(Europe 230 V) 3 A Per Input (Japan 100 V) -
Page 21: Dimensions
Euphonix Max Air Control Surface Manual Dimensions 16.25 75.00° Dimensions in inches 16.13 15.625 8.39 6.78 3.06 2.06 1.20 Figure 10 Side Dimensions .902 .900 KEEP CLEAR FOR VENTILATION 11.723 12.827 KEEP CLEAR FOR VENTILATION 1/4-20 THREADED INSERT 8 PLACES 23.400... -
Page 22: Cm404 Bottom Dimensions
Euphonix Max Air Control Surface Manual 1.79 KEEP CLEAR FOR PROPER VENTILATION 1/4-20 THREADED INSERT 8 PLACES 19.46 21.40 22.30 Figure 12 CM404 Bottom Dimensions 35.43 29.58 0.00 5.85 0.00 Figure 13 Max Air Top Dimensions... -
Page 23: User Reference
Euphonix Max Air Control Surface Manual User Reference Internal Components Dual Power Connections Power Distribution Dual Power Single Board Supplies Computer KVM Extender Figure 14 CM404 Dual Power Connections Dual Power Supplies Power Distribution Single Board Computer Figure 15 CM416... -
Page 24: Fans
Euphonix Max Air Control Surface Manual Fans The CM416 modules have low-noise internal fans and a thermal sensor between the displays on strips five and six. If a module gets too hot, the fans automatically turn on at a low or high speed depending on the temperature. The fans turn off automatically...
