SD942 8ch SD De/Embedder
-In REMOTE mode, local DIP switch settings are not valid. The module must be
BUS-EN **see also
-when OFF, disconnects the outputs to the audio backplane busses on power up
-when ON, connects the outputs to the audio backplane busses on power up
TDM
-when OFF, 2 audio channels are multiplexed per bus line
-when ON, 8 audio channels are multiplexed per bus line
CAN/BUS
-D0 ..D3 : binary combination will set the CAN-ID of the unit from 0 to F
DE-EMBEDDER GROUP A / GROUP B SELECT SWITCHES
- D0/D1: binary combination to set the de-embed group from 1 to 4 (setting:
- CH 1/2, CH 3/4: enables (ON) or disables (OFF) the channel pair in the
EMBEDDER GROUP A / GROUP B SELECT SWITCHES
- D0/D1: binary combination to set the de-embed group from 1 to 4 (setting:
- CH 1/2, CH 3/4: enables (ON) or disables (OFF) the channel pair in the
Initial Setup / Buss Assignment
The SD942 uses web browser interface via the FC972 Remote module to assign its
inputs/outputs to the modular frame audio busses electronically (other modules make use of on-
board jumper settings). Due to this, replacement spares can not be configured until they are
inserted into the frame. However, this may cause conflicts in audio busses and result in
disruption of existing audio signals.
To avoid audio buss conflicts when you replace an SD942, the output bus driver circuits must first
be disabled. This is done by setting the BUS-EN DIP-Switch "OFF." When inserted into the
frame, the module can be initialized which will set all parameters to factory defaults including all
output busses off.
After the proper configuration is entered into the module via web interface, the module should be
removed and the BUS-EN DIP switch set to "ON." The buss configuration will now be taken from
module memory on power-up.
in REMOTE mode to be configured via web browser interface.
Initial Setup / Buss Assignment
Note: This mode is most useful in initial module setup. See Initial
Setup / Buss Assignment
0=GR1 .... 3=GR4).
selected group
0=GR1 .... 3=GR4).
selected group
