Euphonix Modular I/O Configuration Guide
IO95 Modular Frame
Features
19" modular chassis, 3RU, RF shielded
• incl. 2 power supplies PS993 in redundant
mode
• incl. 1 double appliance socket with mains
filter and switch
• dual plane-card installation from both sides
• external dimensions in accordance with DIN
41494, 320mm depth
• aluminum side panels chromated, aluminum
cross extrusions, RF protection by 0.8mm
steel covers, zinc passivated
• Provides four positions for local-side
redundant MADI-over-Fiber interface
Frame Layout
42
Product Data Sheets
1/4
