Euphonix Modular I/O Configuration Guide

1.2.7 WC984 4ch WCLK Out

General Description
Connections, Power Consumption, Width, Weight

1.3 Audio I/O modules

1.3.1 AD914 4ch Mic Input

General Description
Connections, Power Consumption, Width, Weight

1.3.2 AD920 4ch Analog Line Input

General Description
TCP/IP (RJ45), CAN Remote (RJ45) no longer used, RS232
(9pin DSub) for ip address configuration, ~300 mA, 4HP,
~200g.
The WC984 provides four workclock outputs derived from
the frame's sync buss, regardless of the module being used
as the master sync source. Sample rates from 44.1k ~ 96k
are supported. This module is highly recommended from
frames where sync-to-MADI is being used as the sync
method. The module requires no settings.
Wordclock out (BNC x4), ~100 mA, 4HP, ~150g.
The AD914 provides 4 remote controlled preamps with 24 bit
resolution and sample rates up to 96k. Preamps are
controlled via Eucon interface or web browser interface via
the TCP/IP network on the FC972 Remote. On-board
switches are used to link the sources to the frame's audio
busses and to set the device ID.
Analog input (MXLR x4), ~1300mA, 4HP, ~300g.
The AD920 provides 4 analog inputs with 24 bit resolution
and sample rates up to 96k. All settings are done with on-
board switches including buss linking and analog reference
level.
16
Product Description
