Euphonix Modular I/O Configuration Manual page 48

Euphonix Modular I/O Configuration Guide
MM934/MM934opt MADI In/Out
Working Modes on Standard Sampling Rates (44.1/48kHz)
56ch in
MM934
IN/OUT ROUTING
MADI IN
ch1
to
ch56
MADI OUT
MASTER: X
SEL0: OFF
SEL1: OFF
SEL2: ON
64ch in
MM934
IN/OUT ROUTING
MADI IN
ch1
to
ch56
MADI OUT
MASTER: X
SEL0: OFF
SEL1: ON
SEL2: ON
S1...S32
S32
to
S5
56-64: ON
32/32: OFF
16/16: OFF
48/16: OFF
S1...S32
S32
to
S1
56-64: ON
32/32: OFF
16/16: OFF
48/16: OFF
48
56ch out
MM934
IN/OUT ROUTING
MADI IN
MADI OUT
ch1
to
ch56
MASTER: X
SEL0: OFF
SEL1: OFF
SEL2: OFF
64ch out
MM934
IN/OUT ROUTING
MADI IN
MADI OUT
ch1
to
ch56
MASTER: X
SEL0: OFF
SEL1: ON
SEL2: OFF
Product Data Sheets
3/4
S1...S32
S1
to
S28
56-64: ON
32/32: OFF
16/16: OFF
48/16: OFF
S1...S32
S1
to
S32
56-64: ON
32/32: OFF
16/16: OFF
48/16: OFF
