Euphonix Modular I/O Configuration Guide
Connections, Power Consumption, Width, Weight

1.3.3 DA921 4ch Analog Line Output

General Description
Connections, Power Consumption, Width, Weight

1.3.4 AD922 4ch Analog Line Input

General Description
Connections, Power Consumption, Width, Weight

1.3.5 DA923 4ch Analog Line Output

General Description
Connections, Power Consumption, Width, Weight

1.3.6 AD924 4ch Mic Input

Analog input (FXLR x4), ~850mA, 8HP, ~200g.
The DA921 provides 4 analog outputs with 24 bit resolution
and sample rates up to 96k. All settings are done with on-
board switches including buss linking and analog reference
level.
Analog output (MXLR x4), ~650mA, 8HP, ~200g.
The AD922 provides 4 analog inputs with 24 bit resolution
and sample rates up to 96k. All settings are done with on-
board switches including buss linking and analog reference
level.
Analog input (15p DSub), ~850mA, 4HP, ~200g.
The DA923 provides 4 analog outputs with 24 bit resolution
and sample rates up to 96k. All settings are done with on-
board switches including buss linking and analog reference
level.
Analog output (15p DSub), ~650mA, 4HP, ~200g.
17
Product Description
