Euphonix Modular I/O Configuration Guide
Product Data Sheets
1/2
AD924 4ch Microphone Input
Features
• 4ch high performance mic input
• 24bit sigma-delta A/D converter
• sample rate up to 96kHz
• 142dB dynamic range (greater than conventional preamps)
• digital gain setting 0...70dB
• digital audio processing (gain, subsonic filter, phase reverse)
• sophisticated circuit design
• balanced analog inputs
• electrical isolation between channels (floating)
• 48v phantom power
• remote operation via Eucon or web browser interface of up to 256
microphone inputs in a system (64 devices)
Block Diagram
81
