Euphonix Modular I/O Configuration Guide
Connections, Power, Space, Weight

1.1.2 IO94 Stagebox Frame

General Description
Connections, Power, Space, Weight
1.1.3 IO95 Modular Frame (for local-side redundant MADI-over-Fiber
interface)
General Description
(configurable via DIP switched, some disassembly required
to access).
Power (IEEEx2); PSU: autosensing (100~240vAC, 50/60Hz);
input current (internal 5vDC rail at maximum load): 1.5A @
99vAC, 700mA @ 207vAC; output: 5v@12A usable power,
3RU, front-plane module space: 72HP, rear-plane space:
76HP (typical module width: 4HP/8HP), audio connections
will appear on front and rear in typical configurations.
Weight: ~5.3kg.
The IO94 is a 3RU single-sided frame with built-in dual-
redundant PSUs. The frame contains 19 rear-plane slots.
Rear-plane slots 1-4 are "reserved" for the sync source
module(s). Other modules may be fitted here also. Sync,
control, and audio busses are shared by all slots in the frame.
Power (IEEEx2); PSU: autosensing (100~240vAC, 50/60Hz);
input current (internal 5vDC rail at maximum load): 3A @
99vAC, 1.5A @ 207vAC; output: 5v@20A usable power,
3RU, rear-plane space: 76HP (typical module width:
4HP/8HP), audio connections will appear rear only. Weight:
~5.3kg.
The IO95 is a 3RU double-sided frame with removable dual-
redundant PSUs capable of delivering 5v@12A of usable
power. The frame contains 19 rear-plane slots and 18 front-
plane slots for modules. Rear-plane slots 1-4 are "reserved"
for the sync source module(s). Other modules may be fitted
here also. Sync and control busses are shared by all slots in
the frame.
